TMPro module 66 - Yamaha bikes immobox Moric

Name: TMPro module 66 - Yamaha bikes immobox Moric
SKU: TMPRO2M66
Price: 250.00 EUR
Availability: InStock

TMPro module 66 – Yamaha bikes immobox Moric

250,00 € excl. VAT

Module for creating immobilizer transponders for Moric immo boxes used in Yamaha and MBK vehicles. Easy and efficient solution.

Important Information:

We sell new and unused goods (unless stated otherwise)!
Before each shipment, the goods are inspected and/or tested for functionality, if possible.
Delivery times may be affected by the courier service.
We also perform repairs on control units and can assist you.

Memory device is serial eeprom Seiko S29190 SMD8 package.
Eeprom can be located in 2 different position. Click here and here to see where to dig for to reach eeprom.
Expected file size is 128 bytes.
Use TMPro chip or K-JMD transponder.

Written transponder is ready programmed to start bike.

Note: Latest Yamaha immobox Moric DO NOT HAVE serial eeprom, so please check your immobox before purchasing this software. If there is no serial eeprom, but 16 pin chip TMS3705 you need software module 108.

Vehicles equipped with this unit:
Yamaha: BT1100, FJR, FZR, FZ1, FZ6, FZS, XT, XTR, XTX, XVX, YZF
MBK: Skycruiser 125

Important Information: Before purchasing the module, make sure you also have the TMPro2 Transponder Key Programmer. This module cannot function independently!
